Swing Check Valve

Swing Check Valve
Send Inquiry
Product Code : 16
Product Specification
Swing Check Valve
  • Bolted Bonnet, Swivel Type
  • Face to Face dimensions according to as per ANSI B16.10
  • Flange Dimension as per ANSI B16.5
  • Alternative Flanges can be provided.
Nomenclature And Materials

Body
 Cast Steel ASTM A216 Gr. WCB
Stainless Steel ASTM A351 CF - 8/8M
Cover
Disc
Hinge
Seat Ring
 Stainless Steel CA - 15/CF - 8 / 8M
Disc Ring
 13% CR. Deposited
Hinge Pin
 Stainless Steel AISI - 410 / 304
Gasket
 Sprila Wound
Bolts & Nuts
 Carbon Steel / SS - 304

Hydrostatic Test Pressure in Kg/Cm2 (PSI)

Class

Shell

Seat

150

30 (425)

20 (285)

300

77 (1100)

51 (730)

Dimensions Are In MM

Mark
 Size
 50
 65
 80
 100
 125
 150
 200
 250
 300
 350
 400
 450
 500
 600
Class-150

Class-300
 A

A
 203
 216
 241
 292
 333
 356
 495
 622
 699
 787
 864
 978
 978
 1295
267
 292
 318
 356
 400
 445
 533
 622
 711
 838
 864
 978
 1016
 1346
ANSI 16.5
Class-150
 C

D

b

k

d4

d2

z
 130
 210
 248
 285
 405
 394
 483
 533
 591
 667
 691
 733
 775
 911
152
 178
 191
 229
 254
 279
 343
 406
 483
 533
 597
 635
 699
 813
19
 22
 24
 24
 24
 25
 29
 30
 32
 35
 37
 40
 43
 48
121
 140
 152
 2191
 216
 241
 298
 362
 432
 476
 540
 578
 635
 749
92
 105
 127
 157
 186
 216
 270
 324
 381
 413
 470
 584
 584
 692
19
 19
 19
 19
 22
 22
 22
 25
 25
 29
 29
 32
 32
 35
4
 4
 4
 8
 8
 8
 8
 12
 12
 12
 16
 16
 20
 20
ANSI B16.5
Class-300
 D

b

k

d4

d2

z
 165
 191
 210
 254
 279
 318
 381
 445
 521
 584
 648
22
 25
 29
 32
 35
 37
 41
 48
 51
 54
 57
127
 149
 168
 200
 235
 270
 330
 387
 451
 514
 572
92
 105
 127
 157
 186
 216
 270
 324
 381
 413
 470
19
 22
 22
 22
 22
 22
 25
 29
 32
 32
 35
8
 8
 8
 8
 8
 12
 12
 16
 16
 20
 20
  • Testing as per API 598/BS : 5146
  • Outside lever & Weight type can be provided.
  • By Pass / Gear / Actuator can provide.
